DD32/MagicNodes

# MagicNodes — ComfyUI Render Pipeline (SD/SDXL) Simple start. Expert-grade results. Reliable detail. /

TL;DR: MagicNodes, it's a plug-and-play multi-pass "render-machine" for SD/SDXL models. Simple one-node start, expert-grade results. Core is ZeResFDG (Frequency-Decoupled + Rescale + Zero-Projection) and the always-on QSilk Micrograin Stabilizer, complemented by practical stabilizers (NAG, local masks, EPS, Muse Blend, Polish). Ships with a four-pass preset for robust, clean, and highly detailed outputs. Our pipeline runs through several purposeful passes: early steps assemble global shapes, mid steps refine important regions, and late steps polish without overcooking the texture. We gently stabilize the amplitudes of the "image’s internal draft" (latent) and adapt the allowed value range per region: where the model is confident we give more freedom, and where it’s uncertain we act more conservatively. The result is clean gradients, crisp edges, and photographic detail even at very high resolutions and, as a side effect on SDXL models, text becomes noticeably more stable and legible.

Please note that the SDXL architecture itself has limitations and the result depends on the success of the seed, the purity of your prompt and the quality of your model+LoRA.

Draw

Photo Portrait

Photo Cup

Photo Dog

---

Features

• ZeResFDG: LF/HF split, energy rescale, and zero-projection (stable early, sharp late)
• NAG (Normalized Attention Guidance): small attention variance normalization (positive branch)
• Local spatial gating: optional CLIPSeg masks for faces/hands/pose
• EPS scale: small early-step exposure bias
• QSilk Micrograin Stabilizer: gently smooths rare spikes and lets natural micro-texture (skin, fabric, tiny hairs) show through — without halos or grid patterns. Always on, zero knobs, near‑zero cost.
• Adaptive Quantile Clip (AQClip): softly adapts the allowed range per region. Confident areas keep more texture; uncertain ones get cleaner denoising. Tile‑based with seamless blending (no seams). Optional Attn mode uses attention confidence for an even smarter balance.
• MGHybrid scheduler: hybrid Karras/Beta sigma stack with smooth tail blending and tiny schedule jitter (ZeSmart-inspired) for more stable, detail-friendly denoising; used by CADE and SuperSimple by default
• Seed Latent (MG_SeedLatent): fast, deterministic latent initializer aligned to VAE stride; supports pure-noise starts or image-mixed starts (encode + noise) to gently bias content; batch-ready and resolution-agnostic, pairs well with SuperSimple recommended latent sizes for reproducible pipelines
• Muse Blend and Polish: directional post-mix and final low-frequency-preserving clean-up
• SmartSeed (CADE Easy and SuperSimple): set seed = 0 to auto-pick a good seed from a tiny low-step probe. Uses a low-discrepancy sweep, avoids speckles/overexposure, and, if available, leverages CLIP-Vision (with reference_image) and CLIPSeg focus text to favor semantically aligned candidates. Logs Smart_seed_random: Start/End. I highly recommend working with SmartSeed.
• CADE2.5 pipeline does not just upscale the image, it iterates and adds small details, doing it carefully, at every stage.

Hardware

• The pipeline is designed for good hardware (tested on RTX5090 (32Gb) and RAM 128Gb), try to keep the starting latent very small, because there is an upscale at the steps and you risk getting errors if you push up the starting values.
• start latent ~ 672x944 -> final ~ 3688x5192 across 4 steps.
• Notes
  • Lowering the starting latent (e.g., 512x768) or lower, reduces both VRAM and RAM.
  • Disabling hi-res depth/edges (ControlFusion) reduces peaks. (not recommended!)
  • Depth weights add a bit of RAM on load; models live under depth-anything/.

💥 Memory

• At each step, the image is upscaled from the previous step! Keep this in mind, the final image may not fit into your PC's memory if the starting latent is high.

Install (ComfyUI 0.3.60, tested on this version)

Preparing: I recomend update pytorch version: 2.8.0+cu129.

1. PyTorch install: pip install torch==2.8.0 torchvision==0.23.0 torchaudio==2.8.0 --index-url https://download.pytorch.org/whl/cu129
2. CUDA manual download and install: https://developer.nvidia.com/cuda-12-9-0-download-archive?target_os=Windows&target_arch=x86_64&target_version=11&target_type=exe_local
3. Install SageAttention 2.2.0, manualy https://github.com/thu-ml/SageAttention or use script scripts/check_sageattention.bat. The installation takes a few minutes, wait for the installation to finish. p.s.: To work, you definitely need to install SageAttention v.2.2.0, version 1.0.6 is not suitable for pipeline.

Next:

1. Clone or download this repo into ComfyUI/custom_nodes/
2. Install helpers: pip install -r requirements.txt
3. I recomend, take my negative LoRA mg_7lambda_negative.safetensors in HF https://huggingface.co/DD32/mg_7lambda_negative/blob/main/mg_7lambda_negative.safetensors and place the file in ComfyUI, to ComfyUI/models/loras
4. download model depth_anything_v2_vitl.pth https://huggingface.co/depth-anything/Depth-Anything-V2-Large/tree/main and place inside in to depth-anything/ folder.
5. Workflows Folder workflows/ contains ready-to-use graphs:

• mg_SuperSimple-Workflow.json — one-node pipeline (2/3/4 steps) with presets
• mg_Easy-Workflow.json — the same logic built from individual Easy nodes You can save this workflow to ComfyUI ComfyUI\user\default\workflows

6. Restart ComfyUI. Nodes appear under the "MagicNodes" categories.

I strongly recommend use mg_Easy-Workflow workflow + default settings + your model and my negative LoRA mg_7lambda_negative.safetensors, for best result.

🚀 "One-Node" Quickstart (MG_SuperSimple)

Start with MG_SuperSimple for the easiest path:

1. Drop MG_SuperSimple into the graph
2. Connect model / positive / negative / vae / latent and a Load ControlNet Model module
3. Choose step_count (3/4) and Run

or load mg_SuperSimple-Workflow in panel ComfyUI

Notes:

• When "Custom" is off, presets fully drive parameters
• When "Custom" is on, the visible CADE controls override the Step presets across all steps; Step 1 still enforces denoise=1.0
• CLIP Vision (if connected) is applied from Step 2 onward; if no reference image is provided, SuperSimple uses the previous step image as reference
• Step 1 and Step 2 it's a prewarming step.

❗Tips

(!) There are almost always artifacts in the first step, don't pay attention to them, they will be removed in the next steps. Keep your prompt clean and logical, don't duplicate details and be careful with symbols.

0. MG_SuperSimple-Workflow is a bit less flexible than MG_Easy-Workflow, but extremely simple to use. If you just want a stable, interesting result, start with SuperSimple.

1. Recommended negative LoRA: mg_7lambda_negative.safetensors with strength_model = -1.0, strength_clip = 0.2. Place LoRA files under ComfyUI/models/loras so they appear in the LoRA selector.

2. Download a CLIP Vision model and place it under ComfyUI/models/clip_vision (e.g., https://huggingface.co/openai/clip-vit-large-patch14; heavy alternative: https://huggingface.co/laion/CLIP-ViT-H-14-laion2B-s32B-b79K). SuperSimple/CADE will use it for reference-based polish.

3. Samplers: i recomend use ddim for many cases (Draw and Realism style). Scheduler: use MGHybrid in this pipeline.

4. Denoise: higher -> more expressive and vivid; you can go up to 1.0. The same applies to CFG: higher -> more expressive but may introduce artifacts. Suggested CFG range: ~4.5–8.5.

5. If you see unwanted artifacts on the final (4th) step, slightly lower denoise to ~0.5–0.6 or simply change the seed.

6. You can get interesting results by repeating steps (in Easy/Hard workflows), e.g., 1 -> 2 -> 3 -> 3.  Just experiment with it!

7. Recommended starting latent close to ~672x944 (other aspect ratios are fine). With that, step 4 produces ~3688x5192. Larger starting sizes are OK if the model and your hardware allow.

8. Unlucky seeds happen — just try another. (We may later add stabilization to this process.)

9. Rarely, step 3 can show a strange grid artifact (in both Easy and Hard workflows). If this happens, try changing CFG or seed. Root cause still under investigation.

10. Results depend on checkpoint/LoRA quality. The pipeline “squeezes” everything SDXL and your model can deliver, so prefer high‑quality checkpoints and non‑overtrained LoRAs.

11. Avoid using more than 3 LoRAs at once, and keep only one “lead” LoRA (one you trust is not overtrained). Too many/strong LoRAs can spoil results.

12. Try connecting reference images in either workflow — you can get unusual and interesting outcomes.

13. Very often, the image in step 3 is of very good quality, but it usually lacks sharpness. But if you have a weak system, you can limit yourself to 3 steps.

14. SmartSeed (auto seed pick): set seed = 0 in Easy or SuperSimple. The node will sample several candidate seeds and do a quick low‑step probe to choose a balanced one. You’ll see logs Smart_seed_random: Start and Smart_seed_random: End. Seed is: <number>. Use any non‑zero seed for fully deterministic runs.

15. The 4th step sometimes saves the image for a long time, just wait for the end of the process, it depends on the initial resolution you set.

16. The CombiNode node is optional, you can replace it with standard ComfyUI pipelines.

Repository Layout

Repository Layout

MagicNodes/
├─ README.md
├─ LICENSE                      # AGPL-3.0-or-later
├─ assets/
├─ docs/
│  ├─ EasyNodes.md
│  ├─ HardNodes.md
│  └─ hard/
│     ├─ CADE25.md
│     ├─ ControlFusion.md
│     ├─ UpscaleModule.md
│     ├─ IDS.md
│     └─ ZeSmartSampler.md
│
├─ mod/
│  ├─ easy/
│  │  ├─ mg_cade25_easy.py
│  │  ├─ mg_controlfusion_easy.py
│  │  └─ mg_supersimple_easy.py
│  │  └─ preset_loader.py
│  ├─ hard/
│  │  ├─ mg_cade25.py
│  │  ├─ mg_controlfusion.py
│  │  ├─ mg_tde2.py
│  │  ├─ mg_upscale_module.py
│  │  ├─ mg_ids.py
│  │  └─ mg_zesmart_sampler_v1_1.py
│  │
│  ├─ mg_cleanup.py
│  ├─ mg_combinode.py
│  ├─ mg_latent_adapter.py
│  ├─ mg_sagpu_attention.py
│  └─ mg_seed_latent.py
│
├─ pressets/
│  ├─ mg_cade25.cfg
│  └─ mg_controlfusion.cfg
│
├─ scripts/
│  ├─ check_sageattention.bat
│  └─ check_sageattention.ps1
│
├─ depth-anything/              # place Depth Anything v2 weights (.pth), e.g., depth_anything_v2_vitl.pth
│  └─ depth_anything_v2_vitl.pth
│
├─ vendor/
│  └─ depth_anything_v2/        # vendored Depth Anything v2 code (Apache-2.0)
│
├─ workflows/
│  ├─ mg_SuperSimple-Workflow.json
│  └─ mg_Easy-Workflow.json
|
└─ requirements.txt

Module Notes and Guides

A compact set of per‑module notes, knobs, and usage tips covering Control Fusion, CADE 2.5, MG_CleanUp, and the experimental Magic Latent Adapter.

Control Fusion (mg_controlfusion.py, mg_controlfusion_easy.py,)

• Builds depth + edge masks with preserved aspect ratio; hires-friendly mask mode
• Key surface knobs: edge_alpha, edge_smooth, edge_width, edge_single_line/edge_single_strength, edge_depth_gate/edge_depth_gamma
• Preview can optionally reflect ControlNet strength via preview_show_strength and preview_strength_branch

CADE 2.5 (mg_cade25.py, mg_cade25_easy.py)

• Deterministic preflight: CLIPSeg pinned to CPU; preview mask reset; noise tied to iter_seed
• Encode/Decode: stride-aligned, with larger overlap for >2K to avoid artifacts
• Polish mode (final hi-res refinement):
  • polish_enable, polish_keep_low (global form from reference), polish_edge_lock, polish_sigma
  • Smooth start via polish_start_after and polish_keep_low_ramp
• eps_scale supported for gentle exposure shaping

MG_CleanUp (final memory cleanup node)

• Purpose: a tiny end-of-graph node that aggressively frees RAM/VRAM and asks the OS to return freed pages. Place it at the very end of a workflow (ideally right after SaveImage).

• Returns: passthrough LATENT and a small IMAGE preview (32×32). For the cleanup to work, be sure to connect the Preview node to the IMAGE output.

• What it does (two passes: immediate and +150 ms):

  • CUDA sync, gc.collect(), torch.cuda.empty_cache() + ipc_collect()
  • Comfy model manager soft cache drop; when hard_trim=true also unloads loaded models (will reload on next run)
  • Drops lightweight LRU/preview caches (when available)
  • Windows: trims working set (SetProcessWorkingSetSize + EmptyWorkingSet) and best-effort system cache/standby purge
  • Linux: malloc_trim(0) to release fragmented heap back to the OS
  • Logs how much RAM/VRAM was freed in each pass

• Inputs:

  • hard_trim (bool): enable the strongest cleanup (unload models, OS-level trims).
  • sync_cuda (bool): synchronize CUDA before cleanup (recommended).
  • hires_only_threshold (int): run only when the latent longest side ≥ threshold; 0 = always.

Notes:

• Because models are unloaded in hard_trim, the next workflow run may take a bit longer to start (models will reload).
• Use this node only at the end of a graph — it is intentionally aggressive.

Depth Anything v2 (vendor)

• Lives under vendor/depth_anything_v2; Apache-2.0 license

Depth models (Depth Anything v2)

• Place DA v2 weights (.pth) in depth-anything/. Recommended: depth_anything_v2_vitl.pth (ViT-L). Supported names include: depth_anything_v2_vits.pth, depth_anything_v2_vitb.pth, depth_anything_v2_vitl.pth, depth_anything_v2_vitg.pth, and the metric variants depth_anything_v2_metric_vkitti_vitl.pth, depth_anything_v2_metric_hypersim_vitl.pth.
• ControlFusion auto-detects the correct config from the filename and uses this path by default. You can override via the depth_model_path parameter (preset) if needed.
• If no weights are found, ControlFusion falls back gracefully (luminance pseudo-depth), but results are better with DA v2.
• Where to get weights: see the official Depth Anything v2 repository (https://github.com/DepthAnything/Depth-Anything-V2) and its Hugging Face models page (https://huggingface.co/Depth-Anything) for pre-trained .pth files.

MG_ZeSmartSampler (Experimental)

• Custom sampler that builds hybrid sigma schedules (Karras/Beta blend) with tail smoothing
• Inputs/Outputs match KSampler: MODEL/SEED/STEPS/CFG/base_sampler/schedule/CONDITIONING/LATENT -> LATENT
• Key params: hybrid_mix, jitter_sigma, tail_smooth, optional PC2-like shaping (smart_strength, target_error, curv_sensitivity)

Seed Latent (mg_seed_latent.py)

• Purpose: quick LATENT initializer aligned to VAE stride (4xC, H/8, W/8). Can start from pure noise or mix an input image encoding with noise to gently bias content.
• Inputs
  • width, height, batch_size
  • sigma (noise amplitude) and bias (additive offset)
  • Optional vae and image when mix_image is enabled
• Output: LATENT dict { "samples": tensor } ready to feed into CADE/SuperSimple.
• Usage notes
  • Keep dimensions multiples of 8; recommended starting sizes around ~672x944 (other aspect ratios work). With SuperSimple’s default scale, step 4 lands near ~3688x5192.
  • mix_image=True encodes the provided image via VAE and adds noise: a soft way to keep global structure while allowing refinement downstream.
  • For run-to-run comparability, hold your sampler seed fixed (in SuperSimple/CADE). SeedLatent itself does not expose a seed; variation is primarily controlled by the sampler seed.
• Batch friendly: batch_size>1 produces independent latents of the chosen size.

Magic Latent Adapter (mg_latent_adapter.py) !experimental!

• Purpose: small adapter node that generates or adapts a LATENT to match the target model’s latent format (channels and dimensions), including 5D layouts (NCDHW) when required. Two modes: generate (make a fresh latent aligned to VAE stride) and adapt (reshape/channel‑match an existing latent).
• How it works: relies on Comfy’s fix_empty_latent_channels and reads the model’s latent_format to adjust channel count; aligns spatial size to VAE stride; handles 4D (NCHW) and 5D (NCDHW).
• Experimental: added to ease early, experimental support for FLUX/Qwen‑like models by reducing shape/dimension friction. Still evolving; treat as opt‑in.
• Usage: place before CADE/your sampler. In generate mode you can also enable image mixing via VAE; in adapt mode feed any upstream LATENT and the current MODEL. A simple family switch (auto / SD / SDXL / FLUX) controls stride fallback when VAE isn’t provided.
• Notes: quality with FLUX/Qwen models also depends on using the proper text encoders/conditioning nodes for those families; this adapter only solves latent shapes, not conditioning mismatches.

Documentation

• Easy nodes overview and MG_SuperSimple: docs/EasyNodes.md
• Hard nodes documentation index: docs/HardNodes.md

Dependencies (Why These Packages)

• transformers — used by CADE for CLIPSeg (CIDAS/clipseg-rd64-refined) to build text‑driven masks (e.g., face/hands). If missing, CLIPSeg is disabled gracefully.

• opencv-contrib-python — ControlFusion edge stack (Pyramid Canny, thinning via ximgproc), morphological ops, light smoothing.

• Pillow — image I/O and small conversions in preview/CLIPSeg pipelines.

• scipy — preferred Gaussian filtering path for IDS (quality). If not installed, IDS falls back to a PyTorch implementation.

• sageattention — accelerated attention kernels (auto-picks a kernel per GPU arch); CADE/attention patch falls back to stock attention if not present.

Optional extras

• controlnet-aux — alternative loader for Depth Anything v2 if you don’t use the vendored implementation (not required by default).

Preprint

• CADE 2.5 - ZeResFDG

• PDF: https://arxiv.org/pdf/2510.12954.pdf

• arXiv: https://arxiv.org/abs/2510.12954

• CADE 2.5 - QSilk

• PDF: https://arxiv.org/pdf/2510.15761

• arXiv: https://arxiv.org/abs/2510.15761

How to Cite

@misc{rychkovskiy2025cade25zeresfdg,
      title={CADE 2.5 - ZeResFDG: Frequency-Decoupled, Rescaled and Zero-Projected Guidance for SD/SDXL Latent Diffusion Models},
      author={Denis Rychkovskiy},
      year={2025},
      eprint={2510.12954},
      archivePrefix={arXiv},
      primaryClass={cs.CV},
      url={https://arxiv.org/abs/2510.12954},
}

@misc{rychkovskiy2025qsilkmicrograinstabilizationadaptive,
      title={QSilk: Micrograin Stabilization and Adaptive Quantile Clipping for Detail-Friendly Latent Diffusion},
      author={Denis Rychkovskiy},
      year={2025},
      eprint={2510.15761},
      archivePrefix={arXiv},
      primaryClass={cs.CV},
      url={https://arxiv.org/abs/2510.15761},
}
